Anping Mam Ba Wire Mesh MFG Company, which is founded in 1989, has been devoted into wire cloth and
screen media production for 26 years. The company owns 18 patented
products, all of them have been up to EU, GB and ASTM standards.
The company has acquired certificates of ISO 14001 Environmental
Management System, ISO 9001 Quality Management System and OHSAS
18001 Occupation Health Safety Management System.
Mam Ba Wire Mesh MFG Company has a set of strict procedures to
control the quality from materials to final products shipping. Our
woven wire cloth has been widely accepted by clients from North
America, Australia, Europe and Middle East for its high durability,
precision and impact resistance. 90% of our products are used in
international markets because they can be perfectly matched with
various kinds of vibrating screens including international brands.
For all of mining, aggregate, asphalt mixing and road construction
industries, every cent saved from high quality production, fast
parts changes and a longer part wearlife will be eventually
converted into hard profits and real cost reduction of companies.
As the most important part of vibrating screens, a set of
high-quality wire cloth with high accuracy, long wear life and high
anti-impact is the foundation of production quality assurance in
all industries above.
Poly-Ripple Anti-clogging Wire Mesh Screens
Aperture / Opening: Diamond Opening, Weaving Opening, Triangle
Opening
Specification: width up to 2.5m, no length limitation;
Edge: Raw Edge, plated sheathed, hooked, inner plated welded etc.;
Wire Materials: Spring Steel (High Carbon Steel), or Stainless
steel (e.g. 304 & 316)
Poly Ripple Wire Mesh Screens Panels are designed for high abrasion
applications where the material has a tendency to blind or peg.
Produced using abrasion resistant polyurethane profiles molded over
straight and crimped high quality steel wires, Poly Ripple Wire
Mesh Screen could provide superior wear life.
Poly Ripple Anti-clogging Wire Mesh Screens are high production
wire screens developed to enhance cleaning and non-blinding action,
using independently vibrating weft wires. There are various designs
that provide screening accuracy close to traditional wire mesh in
square, triangle or slotted openings. These screens significantly
reduce blinding and pegging in severe applications.
Advantages of the Anti-blocking Screen :
• High open area
• Exceptional cleaning ability
• Suited for applications with a high percentage of near-size
material which is prone to pegging or blinding
• Used for declogging very sticky materials with no flacky products
• Removes fines, produces a cleaner retained product and reduces
blinding of wet and sticky material
There are three types according to weaving way:
A B C
C TYPE: same self cleaning action reinforced for heavier loads and
bed depth.
Some specifications of B type are reference. Special sizes can be at customized.
| Aperture mm | Wire dia mm | Opening area % |
| 1.5 | 1.2-1.25 | 50 |
| 1.75 | 1.2-1.25 | 55 |
| 2 | 1.2-1.6 | 57-51 |
| 2.5 | 1.2-2 | 60-53 |
| 3 | 1.2-2 | 64-57 |
| 3.5 | 1.2-2 | 67-57 |
| 4 | 1.2-2 | 70-62 |
| 4.5 | 1.2-2 | 75-64 |
| 5 | 1.5-2.8 | 71-56 |
| 5.5 | 1.5-2.8 | 69-62 |
| 6 | 1.5-2.8 | 73-60 |
| 6.5 | 2-2.8 | 70-66 |
| 7 | 2-3.15 | 72-67 |
| 7.5 | 2-3.15 | 62-60 |
| 8 | 2-3.15 | 74-69 |
| 8.5 | 2-3.5 | 77-74 |
| 9 | 2-3.5 | 79-69 |
| 10 | 2-3.5 | 80-74 |
| 11 | 2-3.5 | 85-73 |
| 12 | 2-4 | 84-71 |
| 12.5 | 2.5-4 | 80-71 |
| 13 | 3-4 | 73-70 |
| 14 | 3-4 | 82-73 |
| 15 | 3.5-5 | 78-69 |
| 15.5 | 3.5-5 | 78-67 |
| 16 | 3.5-5 | 75-69 |
| 17 | 4-5 | 80-70 |
| 18 | 4-5 | 80-76 |
| 19 | 4-5 | 82-77 |
| 20 | 4-5 | 86-77 |
| 22 | 4-6 | 84-78 |
| 24 | 4-7 | 81-76 |
| 25 | 4-7 | 83-78 |
| 27 | 4-7 | 83-79 |
| 28 | 4-8 | 83-78 |
| 30 | 4-8 | 85-79 |
| 35 | 4-8 | 86-79 |
| 40 | 4-9 | 89-78 |
| 45 | 4-9 | 90-80 |
The Anti-blocking Screen is a method of weaving the wire mesh. The overlap points of warp
are not prominent, and the surface is flat.
Anti-blocking Screen is easy to leak, wear-resistant and corrosion-resistant.
Self-cleaning screens are available in a side-tensioned or
end-tensioned configuration.
